Armored Fiber Patch Cable Single Armored PVC/LSZH
제품 상세 정보:
| 원래 장소: | 중국 |
| 브랜드 이름: | DF/OEM/Nuetral |
| 인증: | CE/ROHS/REACH/ISO9001/ISO14001 |
| 모델 번호: | TK-SC/UPC 0.9mm |
결제 및 배송 조건:
| 최소 주문 수량: | 협상 가능 |
|---|---|
| 가격: | negotiable denpend on QTY |
| 포장 세부 사항: | 물집 상자 + 판지 |
| 배달 시간: | 영업일 기준 5-9일은 수량에 따라 다릅니다. |
| 지불 조건: | Western Union, T/T, MoneyGram/PayPal |
| 공급 능력: | 1000pcs/day |
|
상세 정보 |
|||
| 제품명: | 장갑 섬유 패치 케이블 | 간섭 손실: | 0.3dB 이하 |
|---|---|---|---|
| 반환 손실: | APC SM≥ 60dB MM≥35dB | 케이블 직경: | 3.0mm |
| 커넥터 유형: | LC/APC | 재킷 재료: | 단일 갑옷 |
| 색상: | 파란색 또는 기타 | 케이블 재료: | 스테인레스 스틸 튜브, PVC/LSZH |
| 굽힘 반경: | 40mm | 작동 온도: | -40C~+75C |
| 섬유 직경: | 50/125 | 등급: | 통신 등급 |
| 자격증: | CE/ROHS/도달 | ||
| 강조하다: | single armored fiber patch cable,PVC armored fiber optic cable,LSZH armored fiber patch cable |
||
제품 설명
Armored Fiber Patch Cable Single Armored PVC/LSZH
LC Simplex 0.9mm Fiber Optic Pigtail APC SM G657A1
Armored fiber cable with build-in metal armor can provide stronger protection of the optical fibers than standards fiber optic cables. The rugged armored cables allow optical fiber to be installed in the most hazardous areas, including environments with excessive dust, oil, gas, moisture, or even damage-causing rodents.
Features:
- Connector type SC, LC, FC, ST, E2000 etc. is optional
- Stainless steel tube provides good protection against physical damage.
- Single mode and Multimode; Simplex or Duplex
- Cable 0.9mm, 2.0mm, 2.4mm or 3.0mm with simplex or duplex and 4,6,8,12,24,48 Core
- Custom order length
- Cable out Jacket: PVC, LSZH, OFNP, OFNR etc.
- All parts compliant with ROHS
- IEC standard compatible
- GR-326-CORE Compliant
Parameter:
Why choose TAKFLY - Advantages as follows:
Professional manufacturer:
- With more than 25 years manufacturing experience in Fiber optic products;
- More than 500 assembly workers with 5 years experienced;
- More than 10 R & D Engineers;
- 16 Sets Germany imported Injection Machine and 16 Production Lines;
- More than 30 sets of Testing Machines: OTDR, 3D, VFL, IL & RL test instrument; tension strength tester, Crush Resistance tester, Power meter tester, light checker, etc.
- OEM Brand is acceptable.
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Source Electronic Exhibition, etc.
Quality Control:
- Spot check the raw material incoming inspection before production;
- Fully check after every individual process finished;
- Fully check production half done;
- Fully check the finished products before packing;
- Spot check before shipping;
Delivery:
- Samples: 1-3 working days.
- Mass Production Order: 3-7 working days.
- Packaging: Plastic Bag, Carton and Pallet are available according to your request.
If you're interested in our products or have any doubt, feel free to contact me at any time!
