상세 정보 |
|||
| 연결 구조: | SC | 재료 모양: | 둥근 와이어 |
|---|---|---|---|
| 허용 측면 압력: | 100 (N/100mm) | 허용 인장 강도: | 100n <1000n |
| 핵심: | 단순 듀플렉스 쿼드 | 외피 재료: | PVC, LSZH |
| 케이블 길이: | 1m.3m.5m 또는 사용자 정의 | 작동 온도: | -40C ~+80C |
| 섬유 모드: | 단일 모드 또는 멀티 모드 | 케이블 직경: | 0.9mm, 2.0mm, 3.0mm |
| 작동 파장: | 1310/1550NM | 삽입 손실: | ≤0.3db |
| 반환 손실: | ≥45dB | 교환 가능성: | ≤0.2db |
| 진동: | ≤0.2db | ||
| 강조하다: | SC-LC OM3 fiber optic patch cord,duplex fiber optic cable 2.0mm,OM3 patch cord with 100N tensile |
||
제품 설명
SC-LC Duplex OM3 Fiber Optic Patch-Cord
Product Description
The SC-LC Duplex OM3 Fiber Optic Patch Cord is a high-performance cable designed for connecting devices in signal routing applications. This patch cord features FC (Fixed Connection) connectors with threaded barrel housing, constructed with nickel-plated metal housing for durability.
Key Features
- Low insertion loss and high return loss
- Excellent mechanical endurance
- High credibility and stability
- Superior repeatability and exchangeability
Applications
- Testing equipment
- FTTX+LAN networks
- Optical fiber CATV systems
- Optical communication systems
- Telecommunication infrastructure
Technical Specifications
| Parameter | Unit | FC, SC, LC/ Armoured | ST, MU | MT-RJ, MPO | E2000 |
|---|---|---|---|---|---|
| Insertion loss (typical) | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 |
| Return loss | dB | ≥45 | ≥50 | ≥60 | ≥30 |
| Operating wavelength | nm | 1310, 1510 | 1310, 1510 | ||
| Exchangeability | dB | ≤0.2 | ≤0.2 | ||
| Vibration | dB | ≤0.2 | ≤0.2 | ||
| Operating temperature | °C | -40~75 | -40~75 | ||
| Storage temperature | °C | -45~85 | -45~85 | ||
| Cable diameter | mm | φ3.0, φ2.0, φ0.9 | φ3.0, φ2.0, φ0.9 |
Why Choose Takfly Communications Co., Ltd?
TAKFLY specializes in fiber optic solutions including patch cords, connectors, adapters, and various optical components for telecommunications, broadband, broadcast, CATV, and network industries.
- Fast delivery and competitive pricing
- Professional product and technical support
- Prompt response to inquiries
- Reliable quality with OEM services available
- Long-term warranty
- Value-added services including logistics support
For any questions or inquiries about this product, please feel free to contact us. We welcome your business and look forward to serving you.
