CPR 24C Fiber Optic Patch Cord Data Center MPO Fiber Cable
제품 상세 정보:
| 원래 장소: | 센즈헨, 중국 |
| 브랜드 이름: | Neutral/OEM/Takfly |
| 인증: | CE/ROHS/REACH/CPR/ISO9001/ISO14001 |
| 모델 번호: | MPO 패치 코드 |
결제 및 배송 조건:
| 최소 주문 수량: | 1 |
|---|---|
| 가격: | Negotiable |
| 포장 세부 사항: | PE는 불룩해집니다 |
| 배달 시간: | 0 일 |
| 지불 조건: | 웨스턴 유니온, L/C (신용장), 전신환, 페이팔 |
| 공급 능력: | 100Pcs/day |
|
상세 정보 |
|||
| 핵심: | 24 핵심 | 섬유형: | SM과 MM |
|---|---|---|---|
| 길이: | 1m, 3m, 5m과 주문 제작됩니다. | 케이블 직경: | 3.0mm, 4.5mm |
| 접속구의 형태: | MPO | 케이블 피복: | 라이스존에 |
| 케이블 색: | 노란, 연한 녹청색, 보라색, 라임 그린 | 애플리케이션: | 데이타 센터 |
| 상품 이름: | 광섬유 MPO 패치 코드 | 다른 팬아웃 방식: | MTP, 이용 가능한 LC |
제품 설명
Fiber Optic MPO 24 Cores Patch Cord Data Center MPO-MPO Fiber Cable
Fiber Optic MPO Patch Cord Name:
Fiber Optic 24 Cores MPO-MPO Patch Cord
Fiber Optic MPO Patch Cord Description:
This MPO-MPO Patch Cord is for the 24 Cores, and can do it for SM and MM according to the requirements. Other cores like 8 cores, 12 cores also available.
This type cable diameter is commonly for 3.0mm, and 4.5mm diameter is also available. The MPO patch cord is with very high density, which is widely used in the Data Center with high performance.
Fiber Optic MPO Patch Cord Features:
| Precision molded MT ferrule |
| High precision guide pins for exact alignment |
| Compact design, up to 4,8,12,24 fibers |
| IEC 61754-7 Compliant |
| Cable diameter 3.0mm, and 4.5mm available |
Fiber Optic MPO Patch Cord Applications:
- Telecommunication Networks
- Active Deviced/Transceiver Interface
- Gigabit Ethernet
- CATV, Video and Multimedia
- Premise Installations
- Optical Switch interframe connections
- Data Center
Fiber Optic MPO Patch Cord Specifications:
| Item | LC,SC,ST,FC....... | MPO/MTP | |
| End face type | PC,UPC and APC | PC and APC | |
| Fiber type | SM(G652,G655,G657)；MM(OM1-OM5) | ||
| Core number | 12, 24 | ||
| Cable Diameter | 0.9,2.0,3.0 | Mini Round cable:Max4.5mm； Ribbon cable:Max3.0*5.0mm | |
| Insertion loss(dB) | ≤ 0.3 | Standard:≤0.35/0.7(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max) | |
| Return loss(Min) |
UPC SM:40dB APC SM:60 dB PC MM:25 dB |
SM: APC:60dB | MM: PC:20dB |
| Test Wavelength (nm) | SM:1310/1550 MM:850/1300 | ||
| Repeatability | ≤ 0.1dB | ||
| Durability | ≤ 0.2dB | ||
| Interchangeability | ≤ 0.2dB | ||
Why choose TAKFLY--Advantages as follows:
Professional manufacturer:
- With more than 21 years manufacturing experience in Fiber optic products;
- More than 450 assembly workers with 3 years experienced;
- More than 10 R&D Engineers;
- 16 Sets Germany imported Injection Machine and 16 Production Lines;
- More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, ect.
- OEM Brand is acceptable.
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia ,Global Soure Electronic Exhibition,etc.
Quality Control:
- Spot check the raw material incoming inspection before production;
- Fully check after every individual process finished;
- Fully check production half done;
- Fully check the finished products before packing;
- Spot check before shipping;
Delivery:
- Samples: 1-3 working days.
- Mass Production Order: 3-7 working days.
- Packaging: Plastic Bag, Carton and Pallet are available according to your request.
Price: If your QTY is big, the price could be negotiated.
