48 Cores SC UPC Pigtail Single Mode 2.5M LSZH Jacket
제품 요약
48 Cores SC UPC Pigtail Single Mode 2.5M LSZH Jacket Fiber Optic Pigtail Applications CATV Telecommunication networks Active device termination Local area networks (LANS) Data processing networks Test equipment Wide area networks (WANS) Fiber Optic Pigtail Features Low insertion loss and High ...
Product Custom Attributes
제품명:
48F 광섬유 팬아웃 피그테일
간섭 손실:
0.3dB 이하
반환 손실:
UPC SM≥50dB
섬유 종류:
코닝 SM G652D
팬아웃 직경:
1.6mm/2.0mm
커넥터 유형:
SC/UPC
재킷 재료:
LSZH
색상:
노란색 또는 맞춤형
파장:
1310nm, 1550nm
길이:
10M, 20M 또는 맞춤형
작동 온도:
-20 ℃ ~ 70 ℃
섬유 직경:
9/125
섬유 브랜드:
코닝, YOFC, OFS, 드라카
강조하다:
48 cores fiber optic pigtail
,single mode SC UPC pigtail
,LSZH jacket fiber pigtail
기본 속성
원래 장소:
중국, 심천
브랜드 이름:
DF/OEM/Nuetral
인증:
CE/ROHS/REACH/ISO9001/ISO14001
모델 번호:
TK-PC-48F-SC-OS2-50M
부동산 거래
최소 주문 수량:
협상 가능
가격:
negotiable denpend on QTY
포장 세부 사항:
물집 상자 + 판지
배달 시간:
영업일 기준 5-9일은 수량에 따라 다릅니다.
지불 조건:
서부 동맹, T/T, MoneyGram/Paypal
공급 능력:
1000pcs/day
제품 설명
48 Cores SC UPC Pigtail Single Mode 2.5M LSZH Jacket
Fiber Optic Pigtail Applications
- CATV
- Telecommunication networks
- Active device termination
- Local area networks (LANS)
- Data processing networks
- Test equipment
- Wide area networks (WANS)
Fiber Optic Pigtail Features
- Low insertion loss and High reflection loss
- Good exchange ability
- Good durability
- High temperature stability
- Standard: Telcordia GR-326-CORE
Fiber Optic Pigtail Specifications
| End face type | UPC and APC |
|---|---|
| Fiber type | SM(G652 / G655 / G657)；MM(OM1-OM5) |
| Cable Diameter | 12.5mm(Fiber optic sub unit 2.0mm) |
| Insertion loss | ≤ 0.3 dB |
| Return loss | UPC SM≥50dB, APC SM≥ 60 dB, PC MM ≥ 35 dB |
| Repeatability | ≤ 0.1 |
| Durability | ≤ 0.2dB |
| Interchangeability | ≤ 0.2dB |
| Tensile strength | 0.9mm cable>5N 2.0/3.0mm cable>70N |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -40℃~80℃ |
| Outer Sheath Material | PVC/LSZH or Customized |
| Bending radius(Static/Dynamic) | 10D/20D |
| Length | Customized |
Why choose TAKFLY
Professional manufacturer:
- With more than 21 years manufacturing experience in Fiber optic products
- More than 450 assembly workers with 3 years experienced
- More than 10 R&D Engineers
- 16 Sets Germany imported Injection Machine and 16 Production Lines
- More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, etc.
- OEM Brand is acceptable
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Soure Electronic Exhibition, etc.
Quality Control:
- Spot check the raw material incoming inspection before production
- Fully check after every individual process finished
- Fully check production half done
- Fully check the finished products before packing
- Spot check before shipping
Delivery:
- Samples: 1-3 working days
- Mass Production Order: 3-7 working days
- Packaging: Plastic Bag, Carton and Pallet are available according to your request
If you're interested in our products or have any doubt, feel free to contact me at any time!
